Viair 75P Portable Compressor

Thoroughbred Sku #: VIA00075
Manufacturer Sku #: 00075

Item Options:

Prop 65:
WARNING: Cancer & Reproductive Harm - P65Warnings.ca.gov


$91.64

Universal

Call Us For Free Advice

(859) 737-4966

Call Us For Free Advice

(859) 737-4966
viair_logo

View More Products From

Viair

Product Details

Product Name: Viair 75P Portable Compressor
Manufacturer: Viair
Manufacturer Part #: 00075
Thoroughbred Diesel Part #: VIA00075

The Every Vehicle Carry 75P is a sleek, yet compact portable tire inflator ideal for sedans and hatchbacks. The compressor has a max amp draw of 10A/120W, making it compatible for any compact passenger vehicle on the road. Tire pressure can be monitored using the gauge on the top of the unit. It comes in a steel carrying case with a durable strap.

PLEASE NOTE:
Always check your vehicle’s power port rating for maximum amperage before ordering. The 75P does not work with Presta bicycle valves, unless used with a Presta Valve Adaptor(Included). The 75P does not work with the VIAIR Winterization Kit (P/N 90145).

Viair Features:

  • 60 PSI Gauge
  • Vibration Isolators
  • Press-On Tire Chuck
  • Integrated Metal Storage Case
  • Durable Leather Tipped Handle
  • Accessory Power Plug
  • 3 pc. Inflation Tips Kit
  • Presta Valve Adaptor
  • For more information on Viair call us at 1-859-737-4966.

SPECS

  • CFM: 1.13 @ 0 PSI
  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 100% @ 50 PSI
  • Max. Working Pressure: 50 PSI
  • Max. Amp/Watt Draw: 10A/120W
  • Ingress Protection Rating: IP54
  • Max. Ambient Temp: +158°F
  • Min. Ambient Temp: -4°F
  • Dimensions: 9.64?L x 4.33?W x 9.68?H
  • Net Weight: 4.44 lbs.
  • Power Cord Length: 10 ft.
  • Air Hose Length: 2 ft.

12-VOLT COMPRESSOR - Supply Voltage 13.8 Volts

PSI CFM A BAR LPM A
0 1.13 6 0 32.0 6
10 0.96 7 1.0 25.5 8
20 0.85 8 2.0 21.0 9
30 0.72 9 3.0 17.5 9
40 0.64 9 4.0 13.3 9
50 0.54 9 5.0 11.0 8
60 0.47 9 6.0 9.1 8
70 0.41 8 7.0 7.8 7
80 0.35 8
90 0.32 8
100 0.27 7

FILL RATES

195/70R14 FILL RATE
27 to 35 PSI 1 min. 04 sec. (± 05 sec.)
35 to 44 PSI 1 min. 22 sec. (± 05 sec.)
205/65R16 FILL RATE
27 to 35 PSI 1 min. 07 sec. (± 05 sec.)
35 to 44 PSI 1 min. 29 sec. (± 05 sec.)
