Fox 2.5 Performance Smooth Body IFP HTO REAR Shock - 20-24 Silverado/Sierra 2500HD/3500HD (1.5-2.5" Lift)

Product Nam: Fox 2.5 Performance Smooth Body IFP HTO REAR Shock - 20-24 Silverado/Sierra 2500HD/3500HD (1.5-2.5" Lift)
Manufacturer: Fox Shocks
Manufacturer Part #: 987-24-011
Thoroughbred Diesel Part #: FOX987-24-011

FOX 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping.

Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed; HTO is particularly beneficial after installing heavier, aggressive tires and applications lifted higher than OEM specification.

Bolt-on 2.5 Performance Series HTO shocks to increase damping capacity and ride in comfort with position-sensitive rebound control.

Reviews

Submit a question

Your Name * Email Address *



Your Question *



There are no Questions to display

Close

Your Privacy ChoicesNotice at Collection

PART NUMBER	987-24-011
FEATURES	2.5” Impact extruded 6061-T6 aluminum shock body Type II clear-anodized body plating High-flow velocity-sensitive damping 5/8” hard chrome shaft Internal floating piston (IFP) Hydraulic Top Out (HTO) piston
TRAVEL	9.18
